And gate
Description
it's just an and gate
Related Schematics
T16 Dependency Matrix
Checks for RAW dependencies between source and destination operands. Each entry holds allows for up to two source operands and one destination operands, with disables available for fine operand control.5-bit Operands5 entries3op, 2op, 1op compatible(Not a standalone unit, part of issue logic)
Screen for RAM
Once connected correctly to the RAM, the screen is able to show its contents in a bar style
8 bit barrel shifter version A
3 ticks, excluding input/output busleft shift, right shift, arithmetic right shift, rotate. blue: data input, inverted, 15ss required purple: shift amount input, normal, 15ss required.keep in mind that doing a right shift by X is the same as doing a left shift by -X. please input the 2s complement if you want right shifts. yellow: output, normal, low output red: - disable left shift, use when only doing right shift- disable right shift, use when only doing left shift- disable barrelshifter- disable sign extend, for use with arithmetic right shift
