8 bit barrel shifter version A

Jul 31, 2024 Public
By:
Minecraft
Width
Depth
Height
Version
Redstone
Logic
Your browser does not support the HTML5 canvas tag.

Description

3 ticks, excluding input/output bus
left shift, right shift, arithmetic right shift, rotate.

blue: data input, inverted, 15ss required

purple: shift amount input, normal, 15ss required.
keep in mind that doing a right shift by X is the same as doing a left shift by -X. please input the 2s complement if you want right shifts.

yellow: output, normal, low output

red:
- disable left shift, use when only doing right shift
- disable right shift, use when only doing left shift
- disable barrelshifter
- disable sign extend, for use with arithmetic right shift
