16-bit Double Density(DD) CCA
Description
DD Diagonal CCA. Inputs, located on the underside, are paired and alternate left to right (A0 B0 on the left... A1 B1 on the right... and so on)
4-ticks
16-bit
Related Schematics
Hex Value Clamper
Takes a min value, max value, and an input. Forces the output to be between the min and max value, i.e. if the input value is above the max value, the output becomes the max value. 4 x 3 x 2
