Tuchi_

Tuchi_

Joined Jul 2025

Biography

The Church of Solid State welcomes you.

Stats

3
Schematics
0
Total Likes
T16 Dependency Matrix preview
Tuchi_
Tuchi_
Jul 7, 2025

T16 Dependency Matrix

Checks for RAW dependencies between source and destination operands. Each entry holds allows for up to two source operands and one destination operands, with disables available for fine operand control.5-bit Operands5 entries3op, 2op, 1op compatible(Not a standalone unit, part of issue logic)

6 0 0 59×39×27
.schem
View T16 Dependency Matrix
Open
16-bit Double Density(DD) CCA ALU, Latched preview
Tuchi_
Tuchi_
Jul 7, 2025

16-bit Double Density(DD) CCA ALU, Latched

Diagonal DD CCA with intergrated latch to make the ALU effectively 3t *in a pipeline*.3t + 1t latch16-bitALUified

7 0 0 33×25×15
.schem
View 16-bit Double Density(DD) CCA ALU, Latched
Open
16-bit Double Density(DD) CCA preview
Tuchi_
Tuchi_
Jul 7, 2025

16-bit Double Density(DD) CCA

DD Diagonal CCA. Inputs, located on the underside, are paired and alternate left to right (A0 B0 on the left... A1 B1 on the right... and so on) 4-ticks16-bit

8 0 0 31×25×12
.schem
View 16-bit Double Density(DD) CCA
Open

No Flows Yet

This user hasn't created any visual schematic flows yet.
